Factory price ultra thin 120*50*15mm 30W constant voltage open frame Power Supply With CE RoHS FCC

Short Description:

Overview Quick Details Place of Origin: Guangdong, China Brand Name: ILM Model Number: ILMSP-030 Output Power: 1 – 50W Output Type: Single Input Voltage: 110V-240VAC Output Frequency: 50/60HZ ...


Product Detail

Product Tags

Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ILM
Model Number:
ILMSP-030
Output Power:
1 – 50W
Output Type:
Single
Input Voltage:
110V-240VAC
Output Frequency:
50/60HZ
Output Current:
2.5A max.
Switching power supply:
30W
Power supply:
30W
Output Voltage:
12-48VDC
1. 3 years warranty
2. 85~264VAC full range of input or input select by switch
3. Low cost, High operating reliability at high temperature
4. Forced air cooling by built in DC fan
5. Protections: Over-load, over-voltage, over-current, over-temperature, short circuit protections
Over-load protection: Max.150% (Fold back current limiting, recover automatically after problems removal)
Over voltage protection: Max.135% (Hiccup mode, recovers automatically after faulty problems removal)
6. LED indicator for power on
7. 100% burn-in tests (at full load)
8. Built-in cooling Fan ON-OFF control
9. Suitable for many types of LED lights, LED electronics screen, Industrial control products, instruments & equipements, safety-guard products, advertisements.
10.Life span: greater than 50000hrs
11.MTBF:greater than 250Khrs
12.Withstand voltage: I/P-O/P: 3KVAC, IP-FG:1.5KVAC, DC-FG: 500VAC
13.Working temperature: -10~60°C
Model ILM-12 ILM-24 ILM-48
Rated output 12VDC/30A 24VDC/1.25A 48VDC/0.625A
Rated power 30W 30W 30W
Efficiency 76% 79% 81%
